Specs
Engine 8
Model
4F243T
Engine Manufacturer
KIOTI
Power
73.10 hp (54.50 kW)
Displacement
148.60 cu. in. (2,435 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Turbo Charged
Fuel Capacity
26.40 gal (100 L)
Transmission 8
Transmission
Manual: Power Shuttle
Shuttle
Power Shuttle
Travel Speeds Forward
20
Travel Speeds Reverse
20
Travel Speeds Minimum Speed
0 mph (0 km/h)
Travel Speeds Maximum Speed
23.90 mph (38.50 km/h)
Travel Speeds Min Reverse Speed
0 mph (0 km/h)
Travel Speeds Max Reverse Speed
37.50 mph (23.30 km/h)
PTO 4
PTO Type
Independent
PTO Power
60.90 hp (45.40 kW)
Rear Speed
540 / 540E
Mid Speed
Electric/Hydraulic
Drive Train 3
Brakes
Wet Multi Disc
Clutch
Wet Disc
Steering
Hydraulic Power Steering
Hydraulics 3
Pump
Tandem Gear
Pump Capacity
20.60 gpm (78 lpm)
Lift Capacity
4,327 lb (1,963 kg)
Hitch 4
Type
Three Point
Category
Category 2
Control Type
Electronic Control
Lift Capacity
4,327 lb (1,963 kg)
dimensions 9
Length with Hitch
150.30 in (3,817 mm)
Width
82.10 in (2,085 mm)
Height
105.30 in (2,675 mm)
Wheelbase
85.40 in (2,170 mm)
Ground Clearance
15.75 in (400 mm)
Front Tread
62.90 in (1,597 mm)
Rear Tread
63.90 in (1,623 mm)
Turning Radius
12.80 ft (3.90 m)
Weight
6,814 lb (3,091 kg)
