Specs
Engine 8
Model
4F243T
Engine Manufacturer
KIOTI
Power
66 hp (49.20 kW)
Displacement
148.60 cu. in. (2,435 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Turbo Charged
Fuel Capacity
22.50 gal (85 L)
Transmission 8
Transmission
Manual: Synchro Shuttle
Shuttle
Synchro Shuttle
Travel Speeds Forward
12
Travel Speeds Reverse
12
Travel Speeds Minimum Speed
0.94 mph (1.51 km/h)
Travel Speeds Maximum Speed
21.79 mph (35.07 km/h)
Travel Speeds Min Reverse Speed
0.93 mph (1.49 km/h)
Travel Speeds Max Reverse Speed
21.42 mph (34.48 km/h)
PTO 4
PTO Type
Independent
PTO Power
57.60 hp (43 kW)
Rear Speed
540 rpm
Mid Speed
N/A
Drive Train 3
Brakes
Wet Multi Disc
Clutch
Dry Single Plate
Steering
Mechanical
Hydraulics 3
Pump
Gear
Pump Capacity
17.90 gpm (67.60 lpm)
Lift Capacity
3,594 lb (1,630 kg)
Hitch 4
Type
Three Point
Category
Category 2
Control Type
Position, Draft, Mixed Control
Lift Capacity
3,594 lb (1,630 kg)
dimensions 9
Length with Hitch
145 in (3,685 mm)
Width
70.90 in (1,800 mm)
Height
105.50 in (2,680 mm)
Wheelbase
82.70 in (2,100 mm)
Ground Clearance
16.50 in (420 mm)
Front Tread
57.70 in (1,465 mm)
Rear Tread
55.70 in (1,415 mm)
Turning Radius
10.20 ft (3.10 m)
Weight
5,202 lb (2,360 kg)
