Specs
Engine 8
Model
3F183T
Engine Manufacturer
KIOTI
Power
60 hp (44.70 kW)
Displacement
111.40 cu. in. (1,826 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Turbo Charged
Fuel Capacity
14.80 gal (56 L)
Transmission 9
Transmission
Hydrostatic
Shuttle
Synchronized
Main Gear
None
Travel Speeds Forward
18
Travel Speeds Reverse
18
Travel Speeds Minimum Speed
0 mph (0 km/h)
Travel Speeds Maximum Speed
18.26 mph (29.38 km/h)
Travel Speeds Min Reverse Speed
0 mph (0 km/h)
Travel Speeds Max Reverse Speed
18.26 mph (29.38 km/h)
PTO 4
PTO Type
Independent
PTO Power
48.30 hp (36 kW)
Rear Speed
540 rpm
Mid Speed
2,000 rpm (Optional)
Drive Train 3
Brakes
Wet Multi Disc
Clutch
None
Steering
Hydrostatic Power Steering
Hydraulics 3
Pump
Gear
Pump Capacity
17.90 gpm (67.60 lpm)
Lift Capacity
3,177 lb (1,441 kg)
Hitch 4
Type
Three Point
Category
Category 1
Control Type
Position with Draft Control
Lift Capacity
3,177 lb (1,441 kg)
dimensions 9
Width
65.60 in (1,665 mm)
Wheelbase
75.60 in (1,920 mm)
Ground Clearance
15.70 in (400 mm)
Front Tread
53.30 in (1,355 mm)
Rear Tread
52.50 in (1,324 mm)
Turning Radius
9.97 ft (3.04 m)
Weight
4,529 lb (2,054.30 kg)
Length with Hitch
139.60 in (3,547 mm)
Height
94.10 in (2,390 mm)
