Specs
Engine 8
Model
3HT-S4TM58A
Engine Manufacturer
KIOTI
Power
57.70 hp (43 kW)
Displacement
111.40 cu. in. (1,826 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Turbo Charged
Fuel Capacity
13.20 gal (50 L)
Transmission 8
Transmission
Hydrostatic
Shuttle
Hydrostatic
Travel Speeds Forward
3
Travel Speeds Reverse
3
Travel Speeds Minimum Speed
0 mph (0 km/h)
Travel Speeds Maximum Speed
17.50 mph (28.10 km/h)
Travel Speeds Min Reverse Speed
0 mph (0 km/h)
Travel Speeds Max Reverse Speed
12.20 mph (19.70 km/h)
PTO 4
PTO Type
Independent
PTO Power
37.90 hp (28.30 kW)
Rear Speed
540
Mid Speed
2,000 (optional)
Drive Train 3
Brakes
Wet Multi Disc
Clutch
None
Steering
Hydrostatic Power Steering
Hydraulics 3
Pump
Gear
Pump Capacity
16.50 gpm (62.40 lpm)
Lift Capacity
2,940 lb (1,334 kg)
Hitch 4
Type
Three Point
Category
Category 2
Control Type
Position with Draft Control
Lift Capacity
2,940 lb (1,334 kg)
dimensions 9
Length with Hitch
136.40 in (3,465 mm)
Width
67.10 in (1,705 mm)
Wheelbase Length
75.50 in (1,918 mm)
Ground Clearance
13.40 in (340 mm)
Front Tread
51.10 in (1,297 mm)
Rear Tread
54.30 in (1,380 mm)
Turning Radius
11.04 ft (3.37 m)
Weight
4,027 lb (1,827 kg)
Height
98.40 in (2,500 mm)
