Specs
Engine 7
Model
3HT-S4TH45A
Engine Manufacturer
KIOTI
Power
45 hp (33.60 kW)
Displacement
111.40 cu. in. (1,826 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Fuel Capacity
13.20 gal (50 L)
Transmission 9
Transmission
Hydrostatic
Shuttle
Hydrostatic
Main Gear
Hydrostatic
Travel Speeds Forward
3 Ranges w/ Infinite Speeds
Travel Speeds Reverse
3 Ranges w/ Infinite Speeds
Travel Speeds Minimum Speed
0 mph (0 km/h)
Travel Speeds Maximum Speed
28.10 mph (17.50 km/h)
Travel Speeds Min Reverse Speed
0 mph (0 km/h)
Travel Speeds Max Reverse Speed
19.70 mph (12.20 km/h)
PTO 4
PTO Type
Independent
PTO Power
50.80 hp (37.90 kW)
Rear Speed
540
Mid Speed
2,000 (optional)
Drive Train 3
Brakes
Wet Disc Type
Clutch
None
Steering
Hydrostatic Power Steering
Hydraulics 3
Pump
None
Pump Capacity
16.50 gpm (62.40 lpm)
Lift Capacity
2,940 lb (1,334 kg)
Hitch 4
Type
Three Point
Category
Category 2
Control Type
Position with Draft Control
Lift Capacity
2,940 lb (1,334 kg)
dimensions 9
Length with Hitch
136.40 in (3,465 mm)
Width
70.40 in (1,789 mm)
Wheelbase Length
75.50 in (1,918 mm)
Ground Clearance
11.80 in (300 mm)
Front Tread
51.30 in (1,303 mm)
Rear Tread
56.90 in (1,444 mm)
Turning Radius
11.16 ft (3.40 m)
Weight
4,422 lb (2,006 kg)
Height
93.70 in (2,380 mm)
