Specs
Engine 8
Model
4J243TA-TP5B
Engine Manufacturer
KIOTI
Power
115.30 hp (86 kW)
Displacement
233.90 cu. in. (3,833 cc)
RPM
2,200 rpm
Fuel Type
Diesel
Aspiration
Intercular
Fuel Capacity
47.60 gal (180 L)
Transmission 8
Transmission
Manual: Power Shuttle
Shuttle
Power Shuttle
Travel Speeds Forward
24
Travel Speeds Reverse
24
Travel Speeds Minimum Speed
1.15 mph (1.85 km/h)
Travel Speeds Maximum Speed
23.84 mph (38.36 km/h)
Travel Speeds Min Reverse Speed
1.14 mph (1.83 km/h)
Travel Speeds Max Reverse Speed
23.67 mph (38.10 km/h)
PTO 4
PTO Type
Independent
PTO Power
83.90 hp (62.60 kW)
Rear Speed
540 / 540E / 1000
Mid Speed
N/A
Drive Train 3
Brakes
Wet Multi Disc
Clutch
Wet Multi Disc
Steering
Hydrostatic Power Steering
Hydraulics 3
Pump
Gear
Pump Capacity
32 gpm (121 lpm)
Lift Capacity
8,002 lb (4,410 kg)
Hitch 4
Type
Three Point
Category
Category 2
Control Type
Electronic Control
Lift Capacity
8,002 lb (3,630 kg)
dimensions 9
Length with Hitch
170.78 in (4,338 mm)
Width
88.58 in (2,250 mm)
Height
111.93 in (2,843 mm)
Wheelbase
94.88 in (2,410 mm)
Ground Clearance
18.94 in (481 mm)
Front Tread
65.35 in (1,660 mm)
Rear Tread
70.47 in (1,790 mm)
Turning Radius
12.69 ft (3.87 m)
Weight
10,230 lb (4,640.25 kg)
