Specs
Engine 8
Model
3HT-TH4C
Engine Manufacturer
KIOTI
Power
57.70 hp (43 kW)
Displacement
111.40 cu. in. (1,826 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Intercular
Fuel Capacity
12.70 gal (48 L)
Transmission 8
Transmission
Hydrostatic
Shuttle
Hydrostatic
Travel Speeds Forward
3
Travel Speeds Reverse
3
Travel Speeds Minimum Speed
0 mph (0 km/h)
Travel Speeds Maximum Speed
18.50 mph (29.70 km/h)
Travel Speeds Min Reverse Speed
0 mph (0 km/h)
Travel Speeds Max Reverse Speed
20.80 mph (12.90 km/h)
PTO 4
PTO Type
Independent
PTO Power
33.40 hp (39.30 kW)
Rear Speed
540
Mid Speed
2,000
Drive Train 3
Brakes
Wet Multi Disc
Clutch
None
Steering
Hydrostatic Power Steering
Hydraulics 3
Pump
Gear
Pump Capacity
16.50 gpm (62.40 lpm)
Lift Capacity
2,716 lb (1,232 kg)
Hitch 4
Type
Three Point
Category
Category 2
Control Type
Position
Lift Capacity
2,716 lb (1,232 kg)
dimensions 9
Length with Hitch
126 in (3,202 mm)
Width
62.80 in (1,596 mm)
Wheelbase Length
71.30 in (1,810 mm)
Ground Clearance
14.50 in (368 mm)
Front Tread
49.40 in (1,254 mm)
Rear Tread
49.30 in (1,251 mm)
Turning Radius
102.80 ft (2,610 m)
Weight
3,523 lb (1,598 kg)
Height
96.80 in (2,458 mm)
