Specs
Engine 8
Model
3C100LFH-U2
Engine Manufacturer
KIOTI
Power
24.50 hp (18.30 kW)
Displacement
61.50 cu. in. (1,007 cc)
RPM
3,000 rpm
Fuel Type
Diesel
Aspiration
Intercular
Fuel Capacity
6.70 gal (25.50 L)
Transmission 9
Transmission
Hydrostatic
Shuttle
Hydrostatic
Main Gear
Hydrostatic
Travel Speeds Forward
9
Travel Speeds Reverse
6
Travel Speeds Minimum Speed
0 mph (0 km/h)
Travel Speeds Maximum Speed
9.57 mph (15.40 km/h)
Travel Speeds Min Reverse Speed
0 mph (0 km/h)
Travel Speeds Max Reverse Speed
6.60 mph (10.60 km/h)
PTO 4
PTO Type
Independent
PTO Power
18.50 hp (13.90 kW)
Rear Speed
540 rpm
Mid Speed
2,200 rpm
Drive Train 3
Brakes
Wet Multi Disc
Clutch
Wet Multi Disc
Steering
Hydraulic Power Steering
Hydraulics 3
Pump
Gear
Pump Capacity
7 gpm (26.40 lpm)
Lift Capacity
700 lb (318 kg)
Hitch 4
Type
Three Point
Category
Category 1
Control Type
Position
Lift Capacity
1,500 lb (680 kg)
dimensions 9
Length with Hitch
99.30 in (2,523 mm)
Width
45.90 in (1,168 mm)
Wheelbase
55.10 in (1,400 mm)
Ground Clearance
6.40 in (162 mm)
Front Tread
44.60 in (1,133 mm)
Rear Tread
46 in (1,168 mm)
Turning Radius
8.20 ft (2.54 m)
Weight
1,554 lb (705 kg)
Height
88 in (2,226 mm)
