Specs
Engine 8
Model
3H-TM4B
Engine Manufacturer
KIOTI
Power
39.60 hp (29.50 kW)
Displacement
111.40 cu. in. (1,826 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Intercular
Fuel Capacity
9 gal (34 L)
Transmission 8
Transmission
Manual
Shuttle
Synchronized Shuttle Shift
Travel Speeds Forward
4
Travel Speeds Reverse
3
Travel Speeds Minimum Speed
1.03 mph (1.65 km/h)
Travel Speeds Maximum Speed
15.53 mph (25 km/h)
Travel Speeds Min Reverse Speed
1 mph (1.61 km/h)
Travel Speeds Max Reverse Speed
15.14 mph (24.36 km/h)
PTO 4
PTO Type
Independent
PTO Power
30.90 hp (23 kW)
Rear Speed
540
Mid Speed
2,000 (Optional)
Drive Train 3
Brakes
Wet Disc Type
Clutch
Dry Single
Steering
Hydrostatic Power Steering
Hydraulics 3
Pump
Gear
Pump Capacity
11.30 gpm (42.90 lpm)
Lift Capacity
1,631 lb (740 kg)
Hitch 4
Type
Three Point
Category
Category 1
Control Type
Position
Lift Capacity
1,500 lb (680 kg)
dimensions 9
Width
54.50 in (1,385 mm)
Height
92.90 in (2,360 mm)
Wheelbase
65.70 in (1,670 mm)
Ground Clearance
13.40 in (340 mm)
Front Tread
48.20 in (1,225 mm)
Rear Tread
47.60 in (1,210 mm)
Turning Radius
8.96 ft (2.73 m)
Weight
2,906 lb (1,318 kg)
Length with Hitch
120.90 in (3,070 mm)
