Specs
Engine 8
Model
3A165LWH-U1
Engine Manufacturer
KIOTI
Power
24.50 hp (18.20 kW)
Displacement
100.50 cu. in. (1,647 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Intercular
Fuel Capacity
9 gal (34 L)
Transmission 8
Transmission
Hydrostatic
Shuttle
Hydrostatic
Travel Speeds Forward
3 Ranges, w/ infinite speeds
Travel Speeds Reverse
3 Ranges, w/ infinite speeds
Travel Speeds Minimum Speed
0 mph (0 km/h)
Travel Speeds Maximum Speed
10.01 mph (16.11 km/h)
Travel Speeds Min Reverse Speed
0 mph (0 km/h)
Travel Speeds Max Reverse Speed
11.28 mph (7.01 km/h)
PTO 4
PTO Type
Independent
PTO Power
18.70 hp (13.90 kW)
Rear Speed
540
Mid Speed
2,000 (Optional)
Drive Train 3
Brakes
Wet Disc Type
Clutch
None
Steering
Hydrostatic Power Steering
Hydraulics 3
Pump
Gear
Pump Capacity
11.30 gpm (42.90 lpm)
Lift Capacity
1,631 lb (740 kg)
Hitch 4
Type
Three Point
Category
Category 1
Control Type
Position
Lift Capacity
1,500 lb (680 kg)
dimensions 9
Width
54.50 in (1,385 mm)
Wheelbase
65.70 in (1,670 mm)
Ground Clearance
13.40 in (340 mm)
Front Tread
48.20 in (1,225 mm)
Rear Tread
47.60 in (1,210 mm)
Turning Radius
8.96 ft (2.73 m)
Weight
3,397 lb (1,541 kg)
Length with Hitch
120.90 in (3,070 mm)
Height
92.52 in (2,350 mm)
