Specs
| Cargo Module | (A4Ex+BL) Frame extension, bolsters 4 pairs+bolster lock or (A4) Bolster 4 pairs or (A3) Bolster 3 pairs or (A5Ex+BL) Trailer with frame extension and 5 pair of bolsters + bolster lock |
| Coupling | (C1) Scandinavian low type drawbar with welded swiveling hitch or (C3) Austrian low type drawbar without hitch or (C7) High type Rückmatic overrun drawbar |
| Bolt | Not applicable (with drawbar C1) or (K1) Bolt on turning eye 50mm (100x110) only if C2 or C3 drawbar have been chosen or (K2) Bolt on fixed eye 40mm (100x110) only if C2 or C3 drawbar have been chosen or (K3) Bolt on K-80 eye (100x110) only if C2 or C3 drawbar have been chosen |
| Wheel set | (WH2.6e) Wheels 400/60-15,5 RF-rim, 6 holes or (WH4.6) 480/45-17 RF-rim, 6 holes or (WH0) Without wheels |
| Traffic Requirements | Off-road use or (TK) Road traffic kit (number plate holder frame with LED-s, wheel stoppers) or (WB) Wheel stoppers |
| Brakes | (B0) Without brakes or (B1) Hydraulic brakes 2 wheels or (B2) Hydraulic brakes 4 wheels or (B3) Air brakes 2 wheels or (B4) Air brakes 4 wheels or (B0-C7) Rückmatic overrun bogies with brakes on 2 wheels or (B1-C7) Rückmatic overrun bogies with Rückmatic brakes on 2 wheels and hydraulic brakes on 2 wheels |
| Supply of Hydraulics | (P7+T1+) Piston pump on drawbar, at 650p/min - 50L/min, tank 40L filled with HVPL32 oil or (P0+T0+) Without Hydraulics Supply |
| Control Unit | Without platform or (D1) Platform with back support on the drawbar (PSH option must be selected for crane) or (D2) Platform with back support for trailer with overrun front brakes |
| LED Lights | No Lights or (L2) Rear LED lights Kilpi with flexible arm, reflectors and frame cover |
| Parking support leg | (SL) Removable parking support leg on drawbar |
