Farmi Forest CR69 Crane

Contact us for price

Stock status: Call Store for Availability

Call Us Now

Specs

Grapple (C0) Without grapple or (C18) Grapple for logs 0,18 m2 (FL) or (C23) Grapple for logs 0,23 m2 (FL) or (C25) Grapple 0,25 m2 Grippen (FL) or (C36) Grapple for energy wood 0,21 m2 (FL) or (C25.1) Grapple for logs 0,26 m2 (FL) or (C38) Grapple for energy wood 0,25 (FL) or (GB3) Gravel bucket for C23 grapple 0,24 m3 (FL) or (EBG01) Wide Grapple for energy wood 0,15 m3 (FL)
Supply of Hydraulics Constant Flow hydraulic or Load Sensing hydraulic
Control Unit (A4.2) 4/8 XY+2x el.on-off valve, Bucher HDS16, 215bar or (A7) 4/8 XYZ control valve, Hydro-Control, 190bar, (215 bar by request) or (A11) 2/8 Pre-hydraulic,+2x el.propo, Parker P70, 215bar or (A12) 2/8 Pre-hydraulic,+2x el.propo, Walvoil DPX100, (max 120L/min) 215bar or (AH21) Electrical proportional, Parker L90LS, Parker MC43 controller, 215 bar with Parker IQAN LC6 Joysticks, (LS compatible, speeds and ramps not adjustable by customer) or (AH21BD) Electrical proportional, Parker L90LS, Parker MC43 controller, 215 bar with Parker IQAN LC6 Joysticks with CAN modules, Parker G11 bluetooth dongle, 2 x cable set (LS compatible, speeds and ramps adjustable via Parker free IQANGO app) or (AH21D) Electrical proportional, Parker L90LS, Parker MC43 controller, 215 bar with Parker IQAN LC6 Joysticks, Parker MD3 display, 3 x cable set (LS compatible, speeds and ramps adjustable via MD3 display) or (AH21RCI) Radio control IMET, electrical proportional, Parker L90LS valve block, 215 bar
Crane Base (B0) Without support legs or (BF1) Support legs CR47-CR69+ Flap down type or (BF3) Support legs CR89 flap down type
Accessories No accessories or (W1) Winch 1400 with radio control (winch valve integrated to A11-A41) or (W2) Winch 2200 with radio control (winch valve integrated to A11-A41) or (W0) Main boom ready for winch or (HSB) High Seat on a crane boom
Work Lights with protection on extension boom, 2pcs (L1) Worklights Yes or No
Oil cooling package No oil cooling package or (CP1) Oil cooling package with electrical cable to tractor battery
Electrical floating position for lifting No electrical floating position or (FP) Electrical floating position for lifting and slewing (for A11-AH26.38)
Damping for slewing gear No Damping for slewing gear and lifting cylinder or (D2) Damping for slewing gear and lifting cylinder
Joystick holders No Joysticks or (JL) Pair of joystick holder links for A11-AH26.38
Counter plate for turning device No counter plate or (PL) Counter plate for the turning device
Counter plate for support legs No counter plate or (PL2) Counter plate for the support legs
High pressure oil fillter No oil filter or (HPF) High pressure oil filter
Valve block cover bag (for A4, A4.2, A7, A11, A12 valves) No valve block cover or (VBC) Valve block cover
Crane link (BR2) Double brake
Protection Sleeves for Hoses (PSH) Protection sleeves for hoses
